InLine 88320, 20m, OS2, SC/APC, SC/APC
Varenr.: [8981126] | Producent: Inline | Model-nr.: 88320 | EAN: 4043718295975
Fjernlager
Varen er på fjernlager, leveringstiden er 6-8 hverdager. Mere info
Leveringsalternativer - Velges i kassen
Instabox - Velg din nærmeste pakkeboks
59,00
Posten Norge – Leveres til pakkeboks nær deg
59,00
Posten Norge – Leveres på hentested nær deg
59,00
PorterBuddy - Fleksibel hjemlevering - levert på døren på kvelden
174,00
Posten Norge - Fleksibel hjemlevering - Levering til døren (om kvelden i større byer)
199,00
Vis alle leveringsalternativer (5)
Fraktprisen er basert på levering til dette postnummer:0015 - OSLO Skift postnummer
Oppgi postnummer for levering.
NOK
188,00
eksklusiv MVA 150,40
Totalt inkl. frakt
247,00
Legg til i liste
Denne funksjonen krever at man er logget inn. Opprett en bruker og liste systemet for å holde styr på fremtidige kjøp eller ønskelister.
Send på mail
Connects a fibre outlet to a compatible fibre modem
Additional metal armour:Integrated stainless steel spiral tubing complements the mechanical cable construction.
Matching fibre connection:LC/APC 8° plugs at both ends connect compatible fibre components.
Discreet routing:The white outer jacket blends into light-coloured living and working areas.
Space-saving cable construction:An outer diameter of 3.0 mm ± 0.2 mm allows discreet cable routing.
Halogen-free outer jacket:The cable has a halogen-free outer jacket for discreet indoor installation.
The InLine® fibre optic simplex cable connects a fibre outlet to a compatible fibre modem. It can be used when the modem is not positioned directly at the outlet.
The OS2 singlemode fibre with 9/125 μm supports optical signal transmission through LC/APC connectors at both ends, integrating into existing installations with matching interfaces.
The white, halogen-free outer jacket suits discreet indoor routing. An included test report completes the cable's technical documentation.
Cable type: Fibre optic simplex cable, FTTH
Fibre type: Singlemode, OS2
Fibre core / cladding: 9/125 μm
Fibre specification: I-VH-2E G657.A2
Connectors: LC/APC 8° to LC/APC 8°
Connector polish: APC, 8°
Cable outer diameter: 3.0 mm ± 0.2 mm
Cable construction: Single-fibre
Armour: Flexible stainless steel spiral tubing
Outer jacket: Halogen-free
Jacket colour: White
Insertion loss (IL): < 0.30 dB
Typical insertion loss (IL): < 0.20 dB
Return loss (RL): > 60 dB
Operating temperature: -40 to +85 °C
Storage temperature: -40 to +85 °C
Standards: IEC 61034-2, IEC 60332-3, IEC 60754-2, IEC 61754-20
Documentation: Test report included
Additional metal armour:Integrated stainless steel spiral tubing complements the mechanical cable construction.
Matching fibre connection:LC/APC 8° plugs at both ends connect compatible fibre components.
Discreet routing:The white outer jacket blends into light-coloured living and working areas.
Space-saving cable construction:An outer diameter of 3.0 mm ± 0.2 mm allows discreet cable routing.
Halogen-free outer jacket:The cable has a halogen-free outer jacket for discreet indoor installation.
The InLine® fibre optic simplex cable connects a fibre outlet to a compatible fibre modem. It can be used when the modem is not positioned directly at the outlet.
The OS2 singlemode fibre with 9/125 μm supports optical signal transmission through LC/APC connectors at both ends, integrating into existing installations with matching interfaces.
The white, halogen-free outer jacket suits discreet indoor routing. An included test report completes the cable's technical documentation.
Cable type: Fibre optic simplex cable, FTTH
Fibre type: Singlemode, OS2
Fibre core / cladding: 9/125 μm
Fibre specification: I-VH-2E G657.A2
Connectors: LC/APC 8° to LC/APC 8°
Connector polish: APC, 8°
Cable outer diameter: 3.0 mm ± 0.2 mm
Cable construction: Single-fibre
Armour: Flexible stainless steel spiral tubing
Outer jacket: Halogen-free
Jacket colour: White
Insertion loss (IL): < 0.30 dB
Typical insertion loss (IL): < 0.20 dB
Return loss (RL): > 60 dB
Operating temperature: -40 to +85 °C
Storage temperature: -40 to +85 °C
Standards: IEC 61034-2, IEC 60332-3, IEC 60754-2, IEC 61754-20
Documentation: Test report included
